Static Radial Sealing 3HS

Static radial sealing with high extrusion resistance and increased tightness against leaks in the case of pressure pulsations.

Application Range
Temperature: -35 °C / +110 °C
Standard Material: PUR

Other materials are available for very high or very low operating temperatures. For detailled information, please look at the specific PDF catalogue or contact our application engineers.

Load product catalog

Are you missing materials or dimensions?

Feel free to contact us!

Our sealing experts will be happy to advise you!

+49(201)86606-0 or vk@techno-parts.de

Filter

D [mm] D1 [mm] H [mm]
Min:
Max:
Material selection
Material:
Material No.
V
Profile D [mm] D1 [mm] H [mm] Material Mat. No. V Quantity
3HS 15.00 12.60 2.88 PUR 0051P 2
3HS 16.00 13.60 3.60 PUR 0051P 2
3HS 40.00 34.40 4.00 PUR 0013P 2
3HS 110.00 103.80 4.72 PUR 0064P 2
3HS 30.00 25.40 4.32 PUR 0064P 2
3HS 36.50 32.40 2.80 PUR 0013P 2
3HS 45.00 40.00 4.40 PUR 0090P 2
3HS 19.50 15.00 3.50 PUR 0090P 2
3HS 80.00 74.40 5.30 PUR 0000P 2
3HS 40.00 33.80 4.72 PUR 0064P 2
3HS 100.00 91.60 8.60 PUR 0090P 1
3HS 50.50 46.00 3.50 PUR 0090P 2
3HS 39.20 33.00 4.20 PUR 0090P 1
3HS 140.00 130.80 9.70 PUR 0000P 2
3HS 80.00 74.70 3.80 PUR 0051P 2
3HS 140.00 131.60 0.00 PUR 0090P 1
3HS 90.00 83.00 6.50 PUR 0090P 1
3HS 80.00 75.40 0.00 PUR 0090P 1
3HS 70.00 65.00 4.00 PUR 0013P 2
3HS 57.00 52.20 0.00 PUR 0090P 2
3HS 50.00 45.40 0.00 PUR 0090P 1
3HS 31.00 26.40 4.00 PUR 0051P 2
3HS 14.50 12.00 3.60 PUR 0051P 2
3HS 100.00 93.80 6.90 PUR 0090P 1
3HS 55.00 49.90 5.30 PUR 0090P 1
3HS 45.00 40.00 4.40 PUR 0013P 2
3HS 180.00 171.60 8.60 PUR 0064P 2
3HS 200.00 188.40 12.30 PUR 0090P 1
3HS 36.00 32.00 0.00 PUR 0090P 1
3HS 100.00 94.50 4.70 PUR 0013P 1
3HS 380.00 372.00 8.40 PUR 0064P 2
3HS 24.00 20.00 0.00 PUR 0090P 1
3HS 20.00 16.00 4.64 PUR 0051P 2
3HS 80.00 74.40 4.80 PUR 0013P 2
3HS 40.00 35.40 4.90 PUR 0090P 1
3HS 57.00 50.80 4.72 PUR 0064P 2
3HS 99.00 90.00 4.40 PUR 0066P 2
